APC Smart-UPS X-Series External Battery Pack Rack/Tower, 120 Battery Voltage, 1200 Watts Power, Lead-acid Battery, Enclosed Battery Cartridge, 4U Rackmount, Black | SMX120BP

Easily connect this external battery pack to an existing APC Smart-UPS X to instantly increase the amount of battery runtime to connected devices during a power outage. Please refer to your APC Smart-UPS X manual to confirm compatibility with this external battery back. The battery pack offers easy plug-and-play installation onto an operating APC Smart-UPS, ensuring power availability while runtime capacity is added. Through the APC Smart-UPS’ intelligent battery management and precision charging, the battery pack maintains the UPS system’s performance, reliability, and useful life. The APC battery pack provides scalable runtime to the APC Smart-UPS X, allowing multiple battery packs to be quickly added if the need arises. The battery pack operates equally in tower configuration, standing next to an APC Smart-UPS, or in rack-mount configuration, mounted below the UPS. Package Includes APC SMX120BP External Battery Pack, installation guide, and rack-mounting brackets.
APC Smart-UPS X 120V External Battery Pack Rack/Tower
Extended-run battery systems provide flexible runtime to critical Smart-UPS applications.
Includes: Installation guide, Rack mounting brackets
Hot-swappable batteriesEnsures clean, uninterrupted power to protected equipment while batteries are being replaced
Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.
Rack/Tower convertibleProtects the initial investment in the UPS when migrating from tower to rack-mount environment.
Scalable runtimeAllows additional run time to be quickly added as needed.
User-replaceable batteriesIncreases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Smart-UPS Battery Systems Features & Benefits
Availability
Advanced battery management included
Embedded monitoring at the cell, module, and cabinet level provides a clear picture of battery runtime and health, with the added benefits of predictable, consistent runtime performance and stable cell health.
Multiple battery pack configuration
Connect up to 10 battery packs for extended runtime applications.
Specification
Output Voltage
110 Volts
Input Frequency
50/60 Hz +/- 3 Hz
Input Voltage Range
140 – 280V
Interface Ports
Smartslot
Control Panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control console
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Recharge Time
3 hour(s)
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Cord Length
2.44 meters
Approvals
C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE
Dimensions
Maximum Height 432.00 mm Maximum Width 178.00 mm Maximum Depth 483.00 mm
Shipping Dimensions
Maximum Height 432.00 mm Maximum Width 178.00 mm Maximum Depth 483.00 mm
Weight
17.53 Kg
Shipping Weight
47.73
