APC SMT1000RMI2UC Smart UPS, Line Interactive, 1000VA / 700 Watts Power, 230 Voltage, 4x IEC C13 Outlets, Smart Connect Port + Smart Slot Interface, AVR / LCD, 2U Rackmount, Black | SMT1000RMI2UC

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1000VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C14 input, 4x IEC 320 C13 outlets, and 2x IEC jumper cables. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges.
Output power capacity
700 Watts / 1.0kVA
Rack Height
2U
Output Connections
(2) IEC Jumpers (Battery Backup)
(4) IEC 320 C13 (Battery Backup)
Nominal Output Voltage
230V
Nominal Input Voltage
230V
Input Connections
IEC 320 C14
Manageability
Network manageable
Most models provide remote power management options of the UPS over the network. Many do not have NMC embedded.
Audible alarms
Provides notification of changing utility power and UPS conditions.
Serial connectivity
Provides management of the UPS via a serial port.
LED status indicators
Quickly understand unit and power status with visual indicators.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
Serviceability
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Predictive failure notification.
Provides early-warning fault analysis ensuring proactive component replacement.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Resettable circuit breakers
Enables a quick recovery from overload events.
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Specifications
UPS topology
Line-Interactive
Output power capacity
1 kVA
Output power
700 W
Waveform
Sine
Input operation voltage (min)
151 V
Input operation voltage (max)
302 V
Input frequency
50/60 Hz
Output operation voltage (min)
220 V
Output operation voltage (max)
240 V
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Y
Surge energy rating
459 J
Response time
10 ms
Output voltage Total Harmonic Distortion (THD)
5%
Noise level
45 dB
Surge protection
Y
Web-based management
Y
Auto-restart
Y
Temperature voltage compensation
Y
AC outlet types
C13 coupler
AC outlets quantity
4 AC outlet(s)
USB port
Y
USB port type
USB Type-A
Serial interface
Y
Serial interface type
RJ-45
Ethernet LAN (RJ-45) ports
1
SmartSlot
Y
Battery technology
Sealed Lead Acid (VRLA)
Number of batteries supported
1
Battery life (max)
6 year(s)
Battery recharge time
3 h
Hot-swap battery
Y
Automatic battery test
Y
Cold start
Y
Replacement battery cartridge
APCRBC132
Form factor
Rackmount
Rack capacity
2U
Product colour
Black
LED indicators
Y
Display
LCD
Certification
EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH
Operating temperature (T-T)
0 – 40 °C
Storage temperature (T-T)
-15 – 45 °C
Operating relative humidity (H-H)
0 – 95%
Storage relative humidity (H-H)
0 – 95%
Operating altitude
0 – 3000 m
Non-operating altitude
0 – 15000 m
Sustainability certificates
RoHS
Width
432 mm
Depth
477 mm
Height
86 mm
Weight
28.2 kg
Rack mount kit
Y
Cables included
RS-232, USB cable
Quick installation guide
Y
Resource CD
Y
Software CD
Y
