APC SMX3000RMHV2UNC SMART-UPS X 3000VA RACK/TOWER LCD 200240V WITH NETWORK CARD | SMX3000RMHV2UNC

Overview
Model Name
APC Smart-UPS X 3000VA Rack/Tower LCD 200-240V with Network Card
Includes
CD with software , Rack Mounting support rails , Smart UPS signalling RS-232 cable , Temperature Probe , User Manual , Web/SNMP Management Card
Output
Output Power Capacity
2700 Watts / 3000 VA
Max Configurable Power (Watts)
2700 Watts / 3000 VA
Nominal Output Voltage
230V
Output Voltage Distortion
Less than 5%
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Other Output Voltages
208, 220, 240V
Line Interactive
Waveform Type
Sine wave
Output Connections
(1) IEC 320 C19 (Battery Backup) , (2) IEC Jumpers (Battery Backup) , (8) IEC 320 C13 (Battery Backup)
Input
Nominal Input Voltage
208V , 230V
Input Frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
British BS1363A , IEC-320 C20 , Schuko CEE 7/EU1-16P
Cord Length
2.44 meters
Input voltage range for main operations
140 – 280 V
Other Input Voltages
220 , 240
Maximum Input Current
0 A
Input Breaker Capacity
0 A
Batteries & Runtime
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
0
Battery Slots Empty
0
Typical recharge time
3 hour(s)
Replacement Battery
APCRBC117
RBC Quantity
1
Communications & Management
Interface Port(s)
SmartSlot
Available SmartSlot™ Interface Quantity
0
Pre-Installed SmartSlot™ Cards
AP9631
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators , Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO)
Yes
Surge Protection and Filtering
Surge energy rating
645 Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Data Line Protection
—
Physical
Maximum Height
85.0 mm
Maximum Width
432.0 mm
Maximum Depth
667.0 mm
Rack Height
2 U
Net Weight
37.32 kg
Shipping Weight
45.36 kg
Shipping Height
243.0 mm
Shipping Width
596.0 mm
Shipping Depth
869.0 mm
Master Carton Units
0.0
Master Carton Weight
0.0 lbs
Color
Black
Units per Pallet
8.0
Pallet Dimensions
1000.0 mm
# of Layers per Pallet
4
# of Units per Layer per Pallet
2
Pallet Weight
388.69 kg
Environmental
Operating Environment
0 – 40 °C
Operating Relative Humidity
0 – 95 %
Operating Elevation
0-3000 meters
Storage Temperature
-15 – 45 °C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
55.000 dB
Online Thermal Dissipation
184.000 BTU/hr
Conformance
Approvals
C-tick , CE , EN 50091-1 , EN 50091-2 , EN 55022 Class A , EN 60950 , FCC Part 15 Class A , GOST , IRAM , UL 1778 , VDE
Standard warranty
3 years repair or replace (excluding battery) and 2 year for battery , optional extended warranties available , optional on-site warranties available
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
Battery Directive
Compliant
