Ryzen 9 9900X3D
A powerful desktop CPU, with 2nd gen AMD 3D V-Cache™ Technology for you to enjoy extreme performance for gaming, creating, streaming or any workload you choose.
Specifications
Name
AMD Ryzen™ 9 9900X3D
Family
Ryzen
Series
Ryzen 9000 Series
Form Factor
Desktops, Boxed Processor
Market Segment
Enthusiast Desktop
AMD PRO Technologies
No
Regional Availability
Global
Former Codename
Granite Ridge AM5
Architecture
Zen 5
# of CPU Cores
12
Multithreading (SMT)
Yes
# of Threads
24
Max. Boost Clock
Up to 5.5 GHz
Base Clock
4.4 GHz
L1 Cache
960 KB
L2 Cache
12 MB
L3 Cache
128 MB
Default TDP
120W
Processor Technology for CPU Cores
TSMC 4nm FinFET
Processor Technology for I/O Die
TSMC 6nm FinFET
Package Die Count
3
Unlocked for Overclocking
Yes
AMD EXPO™ Memory Overclocking Technology
Yes
Precision Boost Overdrive
Yes
Curve Optimizer Voltage Offsets
Yes
AMD Ryzen™ Master Support
Yes
CPU Socket
AM5
Supporting Chipsets
A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX512, AVX2, AVX, FMA3, MMX-plus, SHA, SSE2, SSE4.2, SSE4A, SSE4.1, SSE3, SSSE3, SSE, x86-64
Thermal Solution (PIB)
Not Included
Recommended Cooler
Liquid cooler recommended for optimal performance
Max. Operating Temperature (Tjmax)
95°C
OS Support
Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
Connectivity
Native USB 4 (40Gbps)
4
Native USB 3.2 Gen 1 (5Gbps)
1
PCI Express® Version
PCIe® 5.0
Native PCIe® Lanes (Total/Usable)
28 / 24
NVMe Support
Boot, RAID0, RAID1, RAID5, RAID10
System Memory Type
DDR5
Memory Channels
2
Max. Memory
192 GB
System Memory Subtype
UDIMM
Max Memory Speed
2x1R DDR5-5600
ECC Support
Yes (Requires motherboard support)
Graphics Capabilities
Graphics Model
AMD Radeon™ Graphics
Graphics Core Count
2
Graphics Frequency
2200 MHz
USB Type-C® DisplayPort™ Alternate Mode
Yes
Product IDs
Product ID Boxed
100-100001368WOF
Product ID Tray
100-000001368
Key Features
Supported Technologies
AMD EXPO™ Technology, AMD Ryzen™ Technologies
AMD Ryzen 9 9900X3D AM5 Desktop Processor, 12 Core & 24 Threads, Up to 5.5 GHz Boost Clock, AMD Radeon Graphics, 192GB Max Memory, Dual Channel, Black | 100-100001368WOF
$730.00
Granite Ridge AM5
L2 Cache: 12 MB
L3 Cache 128 MB
AMD Radeon™ Graphics
| Brand |
AMD |
|---|---|
| Model |
Ryzen 9 9900X3D |
| Date first available |
11 March; 2025 |
| TDP |
120 W |
| Shipping Weight |
12.51 Kg |
| Shipping Dimensions |
4.00 cm x 12.50 cm x 12.51 cm |
| Series |
AMD Ryzen 9 |
| Core Family |
AMD Ryzen |
| CPU Socket Type |
AM5 |
| Number of Cores |
12-Core |
| Number of Threads |
24 |
| L2 Cache |
12 MB |
| L3 Cache |
128 MB |
| Integrated Graphics |
AMD Radeon |
| Cooling Device |
Cooling device not included – processor only |
| Max Number of PCI Express La |
28 |
| Manufacturing Technology |
4 nm |
| Virtualization Technology Su |
No |
| Hyper Threading Support |
No |
| Maximum Supported Memory |
192 |
| ECC Memory Supported |
Yes |
