Intel Core i7-13700KF 3.4GHz Processor, 13th Gen LGA1700, 16 Cores, 24 Threads, 30M Cache, 128 GB Max Memory, 5.4GHz Max Turbo Freq, 2 Channel DDR5-5600, 3.4GHz P-Core Clock Speed | BX8071513700KF

Power up your productivity, gaming, and content creation with the Intel Core i7-13700KF 3.4 GHz 16-Core LGA 1700 Processor. This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 16 cores— four more than the previous generation— onto a single processor while still fitting the LGA 1700 socket. Designed to provide high performance, the Core i7-13700KF features eight low-voltage Efficient-cores that handle background tasks for multitasking while the eight 3.4 GHz Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
16 Cores & 24 Threads
3.4 GHz P-Core Clock Speed
5.4 GHz Maximum Turbo Frequency
LGA 1700 Socket
30MB Cache Memory
Dual-Channel DDR5-5600 Memory
Hybrid Core Architecture
Unlocked for Overclocking
13th Generation (Raptor Lake)
Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor’s Efficient-cores for multitasking.
Intel Thread Director
The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Intel Deep Learning Boost
Accelerates AI inference to improve performance for deep learning workloads.
Specs
General
CPU Model
Intel Core i7-13700KF (13th Gen)
CPU Socket
LGA 1700
Manufacturing Process
10 nm
Maximum CPU Configuration
1S
Maximum Number of PCIe Lanes
16 (Revision 5.0)
4 (Revision 4.0)
Unlocked
Yes
Performance
Number of Cores
16 (8 x P-Cores + 8 x E-Cores)
Number of Threads
24
Base Clock Speed
P-Core: 3.4 GHz
E-Core: 2.5 GHz
Maximum Boost Speed
P-Core Turbo: 5.3 GHz
E-Core Turbo: 4.2 GHz
L3 Cache
30 MB
Memory Support
Maximum Capacity
128 GB
Memory Support
DDR5 5600 MHz
DDR4 3200 MHz
ECC Memory
No
Channel Architecture
Dual Channel
Optane Memory Support
Yes
Power
Thermal Design Power (TDP)
125 W
Included Thermal Solution
None
Maximum Temperature
212°F / 100°C
Thermal Monitoring Technologies
Yes
Technology
AES Support
Yes
Extension
AVX 2.0, AVX-512, SSE 4.1/4.2
Instruction Set
64-Bit
Virtualization
Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT)
vPro Support
No
Performance Technologies
Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0, Turbo Boost Max 3.0
Security Technologies
Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology
Integrated Graphics
None
