Intel Core i9-13900KS LGA 1700 Processor, 24 Cores & 32 Threads, 36MB Cache, 3.2 GHz P-Core Clock Speed, 6.0 GHz Max Turbo Freq, 2-CH DDR5-ECC Memory, Up to 128GB Max, Intel UHD 770 | BX8071513900KS

Power up your productivity, gaming, and content creation with the Intel Core i9-13900KS 3.2 GHz 24-Core LGA 1700 Processor. This 13th-generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 24 cores— eight more than the previous generation— onto a single processor while still supporting the LGA 1700 socket. Designed to provide exceptional performance, the Core i9-13900KS features 16 low-voltage Efficient-cores that handle background tasks for multitasking while the eight 3.2 GHz Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
Key Features
24 Cores & 32 Threads
3.2 GHz P-Core Clock Speed
6.0 GHz Maximum Turbo Boost Frequency
LGA 1700 Socket
36MB Cache Memory
Dual-Channel DDR5-5600 ECC Memory
Integrated Intel UHD 770 Graphics
Hybrid Core Architecture
Unlocked for Overclocking
13th Generation (Raptor Lake)
Hybrid Core Design
Performance cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor’s Efficient-cores for multitasking.
Intel Thread Director
The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 32 threads is assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Thermal Velocity Boost
Intel Thermal Velocity Boost (TVB) is a technology that unlocks extra CPU performance by pushing the maximum frequency to 6 GHz when thermal headroom and turbo power budget are available. It is ideal for burst workloads that have sudden spikes in CPU utilization, providing a temporary performance boost to help avoid slowdowns.
Adaptive Boost
Intel Adaptive Boost Technology opportunistically increases the all-core turbo frequency beyond previous Turbo Boost clock speeds, even when Thermal Velocity Boost conditions aren’t met. Benefits can be seen with multi-threaded programs that scale with multiple cores, which include many games. It can also help in multitasking situations, such as when gaming, streaming and chatting all at once through different applications.
Integrated Graphics
Driven by Intel Xe architecture, the integrated Intel UHD 770 Graphics deliver fast, rich 3D performance for high-quality visuals with support for either one 7680 x 4320 resolution 8K monitor or up to four 3840 x 2160 resolution 4K displays with high-dynamic range.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Intel Deep Learning Boost
Accelerates AI inference to improve performance for deep learning workloads.
13th Gen Intel Core i9-13900KS desktop processor
Stream, create, and compete at the highest levels. Push your gameplay beyond performance with 13th Gen Intel Core processors.
Game and multitask without interruption.
24 cores (8 P-cores + 16 E-cores).
32 threads.
Push your in-game settings without worrying about background tasks slowing you down.
Up to 6.0 GHz Max Clock Speed. (1)
Unlocked and overclockable. (2)
Designed for the needs of today’s gamers.
The latest version of performance hybrid architecture will push your gameplay beyond performance, giving you the power to do it all.
Performance cores unleash the capability to optimize the latest games and gaming software.
Efficient cores provide multitasking power to work, play, and most importantly game together.
Personalize your PC.
Support for both DDR4 and DDR5 gives you control over your memory configuration. (4)
Support for Thunderbolt 4 technology offers a simple and fast way to connect peripherals.
Connect quickly and without interference with support for Intel Killer Wi-Fi 6/6E (Gig+). (5)
Enhanced overclocking for both sets of cores allows you to customize your performance. (2)
Tech Specs
CPU Socket Type
LGA 1700
Core Name
Raptor Lake
# of Cores
24-Core (8P+16E)
# of Threads
32
Operating Frequency
P-core Base Frequency: 3.2 GHz
E-core Base Frequency: 2.4 GHz
Max Turbo Frequency
P-core Max Turbo Frequency: Up to 5.4 GHz
E-core Max Turbo Frequency: Up to 4.3 GHz
L2 Cache
32MB
L3 Cache
36MB
Memory Types
DDR4 3200 / DDR5 5600
Memory Channel
2
Max Memory Size
128 GB
ECC Memory
Supported
Integrated Graphics
Intel UHD Graphics 770
PCI Express Revision
PCIe 5.0 & 4.0 support
Max Number of PCI Express Lanes
20
Thermal Design Power
150W
Cooling Device
Cooling device not included – Processor Only
Windows 11
Supported
