Synology DiskStation DS224+ 2-Bay NAS Enclosure, Intel Celeron J4125 4-core 2.0 Base, 2GB RAM, 3.5″ HDD & 2.5″ SSD Compatible, 2x RJ-45 1GbE LAN & 2x USB 3.2 Gen 1 Ports, Black | DS224+

Specifications
CPU
CPU Model
Intel Celeron J4125
CPU Quantity
1
CPU Architecture
64-bit
CPU Frequency
4-core 2.0 (base) / 2.7 (burst) GHz
Hardware Encryption Engine (AES-NI)
Yes
Memory
System Memory
2 GB DDR4 non-ECC
Total Memory Slots
1
Maximum Memory Capacity
6 GB (2 GB + 4 GB)
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays
2
Compatible Drive Type*
3.5″ SATA HDD
2.5″ SATA SSD
Hot Swappable Drive*
Yes
Notes
“Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port
2 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*
2
USB Copy
Yes
Notes
This device’s 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT
Appearance
Size (Height x Width x Depth)
165 mm x 108 mm x 232.2 mm
Weight
1.30 kg
Others
System Fan
92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Yes
Power Recovery
Yes
Noise Level*
22 dB(A)
Scheduled Power On / Off
Yes
Wake on LAN / WAN
Yes
Power Supply Unit / Adapter
60 W
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
14.69 W (Access)
4.41 W (HDD Hibernation)
British Thermal Unit
50.09 BTU/hr (Access)
15.04 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 60°C (-5°F to 140°F)
Relative Humidity
5% to 95% RH
Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
CCC
KC
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 2
Quick Installation Guide X 1
Optional Accessories
DDR4 non-ECC SODIMM: D4NESO-2666-4G
3.5″ SATA HDD: HAT3300
Surveillance Device License Pack
