Asus TUF X299 Mark 2 ATX Motherboard (LGA 2066, Intel X299, DDR4, SATA 6Gb/s USB 3.1, Dual M.2) | 90MB0UB0-M0EAY0

Unconditionally Tough.
24/7 Reliability.
TUF X299 Mark 2 is the durable ATX motherboard made for enthusiasts, modders and gamers who demand reliable performance day in, day out. It’s engineered with Industry-leading cooling controls and temperature monitoring, enabling you to build a system that’s efficiently cooled and supremely stable. Some of the world’s most respected independent testing laboratories have certified TUF components as fit for military use. Every board is subjected to rigorous testing and validation procedures, including warp and drop tests — so you know that TUF X299 Mark 2 will stand up to whatever you throw at it. In fact, we’re so confident of the reliability and durability of our products that each and every TUF motherboard.
ASUS Pro Clock II Technology
DEDICATED DESIGN FOR OVERCLOCKING
TUF X299 Mark 2 includes a dedicated base-clock (BCLK) generator to extend CPU and memory overclocking margins. This custom solution works in tandem with the TPU to enhance voltage and BCLK overclocking control, providing the flexibility to extract every ounce of performance from the Intel Core X-series processors.
ASUS T-Topology
MAKE YOUR MEMORY GO FASTER
ASUS T-Topology allows memory frequencies that are higher than ever — to 4133MHz and beyond. ASUS-exclusive T-Topology circuit design provides superb memory-overclocking capability to unleash the full power of DDR4 by minimizing coupling noise and signal reflection. Refined manufacturing ensures ultra-consistent quality, minimal crosstalk between custom trace paths, and time-aligned signaling for superior stability and compatibility.
Thermal Radar 3
INSTANT FAN TUNING, COMPLETE SYSTEM COOLING
Our Thermal Radar 3 software allows you to control connected chassis fans, water pumps, AIOs, and even the fans of ASUS graphics cards — all to provide ultimate cooling performance for gaming and productivity. Multiple onboard sensors also enable the temperatures of key components to be monitored in real time, so you can assess and optimize cooling efficiency.
24/7 reliability
You demand 24/7 reliability — and we’ve delivered! TUF motherboards undergo the industry’s most punishing tests to ensure they’re ready for long-term duty in any environment. In our tests we overheat them, chill them, bend them, shock them and drop them — so you know that your TUF motherboard is certified for 24/7 reliability!
SafeSlot
PROTECT YOUR GRAPHICS CARD INVESTMENT
SafeSlot is the PCIe slot reinvented by ASUS and engineered to provide superior retention and shearing resistance. Manufactured in a single step using a new insert-molding process, SafeSlot integrates the slot with fortifying metal for an inherently stronger slot, which is then firmly anchored to the PCB through additional solder points.
TUF ESD Guards 2
2X-STRONGER ESD PROTECTION
ESD Guards 2 protects TUF X299 Mark 2 from damaging electrostatic discharge. ESD Guards 2 is tested to levels that are 2X higher than industry standards. We also perform pin-level* testing at 30%-higher ESD levels than previous TUF standards. Our stringent tests mean greater component longevity for your TUF motherboard!
USB 3.1 Gen 2 connector
With backward-compatible USB 3.1 Gen 2 Type-A, you’ll experience ultimate connection flexibility and blazing data-transfer speeds of up to 10Gbps.
Speed up with onboard M.2 up to 32Gbps
With x4 PCI Express 3.0/2.0 bandwidth, TUF X299 Mark 2’s dual M.2 supports up to 32Gbps data-transfer speeds. It’s the perfect choice for an operating system or application drive, providing fast access to data.
Intel VROC support
Unleash the TUF X299 Mark 2 Virtual RAID on CPU (VROC) feature with the addition of an ASUS Hyper M.2 X16 Card, which allows you to attach up to four PCIe 3.0 x16 M.2 drives — for a total bandwidth of up to 128Gbps. With VROC, you can utilize CPU PCIe lanes to configure a bootable RAID array, eliminating traditional DMI bottlenecks, so that storage transfers aren’t held back by other traffic.
Intel Optane memory ready
Intel Optane is a revolutionary non-volatile memory technology supported by TUF X299 Mark 2. Intel Optane memory modules accelerate attached storage to reduce boot and load times, so everything feels faster and more responsive.
Intel Gigabit LAN
MORE THROUGHPUT, LESS CPU USAGE AND GREAT GAMING EXPERIENCES
Don’t let slow networking disrupt your workflow! With Intel Gigabit Ethernet connectors, TUF X299 Mark 2 keeps your data moving swiftly and efficiently. With LAN port, you’ll benefit from increased bandwidth for more speed, automated load balancing for smoother data flows, and instant failover if something should go wrong — so access to your files is always fast, efficient and uninterrupted.
Turbo LAN
NETWORK-OPTIMIZATION SOFTWARE FOR CUSTOMIZABLE PACKET PRIORITIZATION
Turbo LAN with cFosSpeed traffic-shaping technology allows you to configure application priority via an intuitive interface, and reduces network lag – by up to 1.45X!
TUF LANGuard
MILITARY-GRADE LAN PROTECTION
TUF LANGuard, a military-grade innovation that integrates advanced signal-coupling technology and premium surface-mounted capacitors to improve throughput — protecting the motherboard from lightning strikes and static electricity.
AUDIO SHIELDING
Separates analog/digital signal domains, significantly reducing multi-lateral interference.
UNIQUE POP-REDUCING CIRCUIT
Reduces start-up popping noise to all audio outputs.
INTEGRATED AMPLIFIER
Capable of driving high-impedance headphones, without rolling-off high or low frequencies.
DEDICATED CHANNEL LAYOUTS
Separate layers for left and right channels to guard the quality of the sensitive audio signals.
PREMIUM JAPANESE-MADE AUDIO CAPACITORS
Premium parts provide an immersive sound signature, with exceptional fidelity.
Aura Sync
A well-tuned enthusiast system deserves a matching aesthetic. ASUS Aura Sync offers full RGB lighting control with a variety of functional presets for the built-in RGB LEDs. And it can all be synced with an ever-growing portfolio of Aura-capable ASUS hardware.
Intel CPU and Chipset features
INTEL X299 CHIPSET
The Intel X299 chipset supports LGA 2066-socket Intel Core X-series processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, X299 provides a maximum 10 USB 3.1 Gen 1 ports, 8 SATA 6Gbps ports and 32Gbps M.2 support for faster data retrieval.
INTEL CORE X-SERIES PROCESSORS FOR LGA 2066 SOCKET
Intel Core X-series processors (6-core and above): 4-channel (8-DIMM), 44/28 PCI Express 3.0/2.0 lanes. Intel Core X-series processors (4 core): 2-channel (4-DIMM), 16 PCI Express 3.0/2.0 lanes.
CPUIntel Socket 2066 Core X-Series Processors * The Intel Turbo Boost Max Technology 3.0 support depends on the CPU types ChipsetIntel X299 MemoryIntel Core X-series Processors (6-core above) 8 x DIMM, Max. 128GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Intel Core X-series Processors (4-core) 4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory * Hyper DIMM support is subject to the physical characteristics of individual CPUs. Multi-GPU SupportSupports NVIDIA Quad-GPU SLI Technology Supports NVIDIA 3-Way SLI Technology Supports NVIDIA 2-Way SLI Technology Supports AMD Quad-GPU CrossFireX Technology Supports AMD 3-Way CrossFireX Technology Expansion Slots44-Lane CPU- 3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8) 1 x PCIe 3.0 x4 (max at x2 mode) *1 2 x PCIe 3.0/2.0 x1 28-Lane CPU- 2 x PCIe 3.0/2.0 x16 (x16, x16/x8) 1 x PCIe 3.0 x4 (max at x2 mode) *1 2 x PCIe 3.0/2.0 x1 16-Lane CPU- 2 x PCIe 3.0/2.0 x16 (x16 or dual x8) 1 x PCIe 3.0 x4 (max at x2 mode) *1 2 x PCIe 3.0/2.0 x1 StorageIntel X299 Chipset : 1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x M.2 x4 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s port(s) Support Raid 0, 1, 5, 10 Supports Intel Smart Response Technology Intel Rapid Storage Technology 15 support Support Intel Rapid Storage Technology enterprise 5.1 for X-Series(6-core and above) CPU RAID Intel Optane Memory Ready LANIntel I219V, 1 x Gigabit LAN Controller(s), featuring Turbo LAN ASUS Turbo LAN Utility AudioRealtek ALC S1220A 8-Channel High Definition Audio CODEC – Impedance sense for front and rear headphone outputs – Internal audio Amplifier to enhance the highest quality sound for headphone and speakers – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature : – Optical S/PDIF out port(s) at back panel – Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals – Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity – Unique de-pop circuit: Reduces start-up popping noise to audio outputs Separate layer for left and right track, ensuring both sound deliver equal quality USB PortsASMedia USB 3.1 Gen 2 controller : 2 x USB 3.1 Gen 2 port(s) (Type-A) Intel X299 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board) Intel X299 Chipset : 6 x USB 2.0 port(s) (4 at back panel, , 2 at mid-board) Special FeaturesOC Design – ASUS PRO Clock Technology TUF Features: TUF ENGINE! Power Design : – 7 +1 Digital Phase Power Design – TUF Components (Choke, Cap. & MOSFET; certified by military-standard) Ultimate COOL! Thermal Solution : – TUF Thermal Armor – Thermal Radar 3 Safe & Stable! Guardian Angel : – TUF ESD Guards 2 – TUF LANGuard AURA : – Aura Lighting Control – Aura Lighting Effects Synchronization with compatible ASUS ROG devices ASUS Exclusive Features : – MemOK! – AI Suite 3 – Ai Charger – ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface – Turbo LAN File Transfer – Cloud GO! – File Transfer ASUS EZ DIY : – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode – Multi-language BIOS ASUS Q-Design : – ASUS Q-Shield – ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED) – ASUS Q-Slot – ASUS Q-DIMM – ASUS Q-Connector Back I/O Ports1 x PS/2 keyboard/mouse combo port(s) 1 x LAN (RJ45) port(s) 2 x USB 3.1 Gen 2 Type-A 4 x USB 3.1 Gen 1 4 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jack(s) Internal I/O Ports1 x AAFP connector 2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 1 x M.2_FAN connector 1 x VROC_HW_Key 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 2 x Chassis Fan connector(s) 1 x AIO_PUMP connector 1 x H_AMP fan connector 1 x W_PUMP+ connector 1 x Thunderbolt header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x System panel(s) (Q-Connector) 1 x MemOK! button(s) 1 x Thermal sensor connector(s) 1 x Clear CMOS jumper(s) 1 x 5-pin EXT_FAN(Extension Fan) connector 2 x 3D Mount screw port(s) 1 x CPU_OV jumper BIOS128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information ManageabilityWfM 2.0, DMI 3.0, WOL by PME, PXE Support DiscDrivers ASUS Utilities EZ Update Anti-virus software (OEM version) Operating SystemWindows 10 64-bit Form FactorATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
