Specifications
GPU
AMD Radeon™ RX 7800 XT Graphics Card
Technology
5nm GPU, AMD RDNA™ 3 Architecture
Engine Clock
Boost Clock: Up to 2565 MHz
Game Clock: Up to 2254 MHz
Stream Processors
3840
Compute Units
60 CU (with RT+AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
60
Memory Size/Bus
16GB/256-bit GDDR6
Memory Clock
19.5 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMI™: 7680×4320
DisplayPort 2.1: 7680×4320
Interface
PCI-Express 4.0 x16
Output
2x HDMI
2x DisplayPort
BIOS Support
Dual UEFI
Game Index
4K
Sapphire Features
Dual BIOS
TriXX Software Switch
Premium Digital Power Design
Ultra High Performance Conductive Polymer Aluminum Capacitors
Fuse Protection
Tri-X Cooling Technology
High TG Copper PCB
Optimized Composite Heatpipe
Intelligent Fan Control
Precision Fan Control
Metal Backplate with ARGB
ARGB Light Bar
Two-Ball Bearing Fans
Angular Velocity Fan Blade
Assistive System Fan Control
Cold Rolled Steel Frame
Dedicated VRM Cooling
Wave Fin Design
V Shape Fin Design for GPU Cooling
TriXX Supported
Fan Check
Fan Quick Connect
TriXX Boost
NITRO Glow
External RGB LED MB Synchronization
Accessories Bundled
Graphics Card Supporter
ARGB Extension Cable
AMD Features
AMD RDNA™ 3 Architecture
60 AMD RDNA™ 3 Compute Units
64MB AMD Infinity Cache™ Technology
DisplayPort™ 2.1 Support
AMD Radiance Display™ Engine
16GB GDDR6 on 256-Bit Memory Bus
PCI® Express 4.0 ready
AMD FidelityFX™ Super Resolution technology
Microsoft® DirectX® 12 Ultimate Support
Microsoft® DirectStorage Support
Vulkan® Optimized
AMD Smart Technologies
AMD Software: Adrenalin Edition™
AMD Noise Suppression
AMD Privacy View
AMD Radeon™ Super Resolution technology
AMD Link
AMD FreeSync™ Technology
Cooler Type
3 Fans
Form Factor
3 slot, ATX
Dimension: 320(L) x 134.85(W) x 61.57(H) mm
Power Consumption
288W Total Board Power
OS
Linux®, Windows® 10, and Windows 11 (64-bit)
System Requirement
Minimum 700 Watt Power Supply
2 x 8-pin Power Connector
PCI Express® based PC with one X16 lane graphics slot available
Minimum 8GB system memory, 16GB recommended
Sapphire NITRO+ AMD Radeon RX 7800 XT Graphics Card, 16GB GDDR6 256-Bit Memory, 2565 MHz Boost Clock, 19.5Gbps Memory Clock, 3840 Stream Processors, PCI-Express 4.0 x16 | 11330-01-20G
$660.00
GPU: Boost Clock: Up to 2565 MHz
GPU: Game Clock: Up to 2254 MHz
Memory: 16GB/256 bit DDR6. 19.5 Gbps Effective
Stream Processors: 3840
RDNA™ 3 Architecture
Ray Accelerator: 60
| Brand |
SAPPHIRE |
|---|---|
| Model |
NITRO+ AMD Radeon RX 7800 XT |
| Date first available |
28 January; 2025 |
| Shipping Weight |
1.40 Kg |
| Shipping Dimensions |
9.00 cm x 43.00 cm x 24.51 cm |
| GPU |
RX 7800 XT |
| Chipset Manufacturer |
AMD Chipset |
| Memory Size |
16 GB |
| Multi-GPU Support |
— |
| Max Resolution |
7680×4320 |
| Memory Type |
GDDR6 |
| Memory Interface |
256 Bit |
| HDMI |
Yes |
| DVI |
No |
| D-SUB (VGA) |
No |
| Display Port |
Yes |
| Effective Memory Clock |
19.5Gbps |
| Form Factor |
RX |
| Interface |
PCI Express 4.0 |
| TDP |
288 W |
| Maximum Display Support |
4 |
| Cooling |
3 Fans |
| Power Connectors |
2 x 8-pin Power Connector |
