Sapphire NITRO+ AMD Radeon RX 9070 XT Graphics Card, 16GB GDDR6 256-Bit Memory, 3060 MHz Boost Clock, 4096 Stream Processors, 20 Gbps Memory Clock, PCI-Express 5.0 x16 | 11348-01-20G

Specifications
GPU
AMD Radeon™ RX 9070 XT
Architecture
AMD RDNA™ 4
Engine Clock
Boost Clock: Up to 3060 MHz
Game Clock: Up to 2520 MHz
Stream Processors
4096
Compute Units
64 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
64
AI Accelerators
128
Memory Size/Bus
16GB / 256-bit GDDR6
Memory Clock
20 Gbps Effective
Display Support
Maximum 4 Displays
Resolution
HDMI®: 7680×4320
DisplayPort™ 2.1a: 7680×4320
Interface
PCI-Express 5.0 x16
Output
2x HDMI®
2x DisplayPort™ 2.1a
BIOS Support
UEFI
Game Index
4K
Sapphire Features
Quick Connect MagniPlate
STEALTH Hidden Power Cable
12V-2×6(H++) External Power Connector
Honeywell PTM7950 TIM
AeroCurve Fan Blade
Free Flow
FrameDefense
Integrated Cooling Module
Cold Rolled Steel Frame
Tri-X Cooling Technology
High TG Copper PCB
Optimized Composite Heatpipes
Metal Backplate
ARGB Light Bar
Fan Quick Connect
Two-Ball Bearing Fans
Premium 16-Phase Digital Power Design
Fuse Protection
Intelligent Fan Control
Precision Fan Control
TriXX Supported Features
Performance vs. Efficiency Quicksets
Glow!
Fan Check
TriXX Boost
External RGB LED MB Synchronization
Accessories Bundled
L-Shape Support Bracket
3-pin 5V ARGB Cable
Magnetic Backplate
12V-2×6(H++) to PCI Express 3×8-pin power adapter
AMD Features
AMD HYPR-RX with AFMF 2
AMD FidelityFX™ Super Resolution 4 with AI Upscaling
DisplayPort™ 2.1a
AMD Radiance Display™ Engine
AMD Fluid Motion Frames 2
AMD Radeon™ Anti-Lag 2
AV1 Encode/Decode
AMD FidelityFX™ technologies
Microsoft® DirectX® 12 Ultimate
AMD Noise Suppression
AMD FreeSync™ technology
AMD Smart Technologies
AMD Software: Adrenalin Edition™
Cooler Type
Tri-X Cooling
AeroCurve Fan Blade
Free Flow
Integrated Cooling Module
High TG Copper PCB
Optimized Composite Heatpipes
Two-Ball Bearing
Form Factor
3.2 slot, ATX
Dimensions
330.8mm (L) x 128.5mm (W) x 65.68mm (H)
Power Consumption
330W Typical Board Power
Supported OS
Linux®, Windows® 10, and Windows® 11 (64-bit required)
System Requirements
Minimum 750W Power Supply
12V-2×6(H++) Power Connector (3×8-pin power adapter included)
PCI Express® based PC with one X16 lane graphics slot
Minimum 8GB of system memory (16GB recommended)
