Cisco C1000-8FP-2G-L Catalyst 1000 Series Switches, 8x 10/100/1000 Ethernet PoE+ Ports & 120W PoE Budget, 2x 1G SFP and RJ-45 Combo Uplinks | C1000-8FP-2G-L

C1000-8FP-2G-L
Cisco® Catalyst® 1000 Series Switches are fixed managed Gigabit Ethernet enterprise-class Layer 2 switches designed for small businesses and branch offices. These are simple, flexible and secure switches ideal for out-of-the-wiring-closet and critical Internet of Things (IoT) deployments. Cisco® Catalyst® 1000 operate on Cisco IOS® Software and support simple device management and network management via a Command-Line Interface (CLI) as well as an on-box web UI. These switches deliver enhanced network security, network reliability, and operational efficiency for small organizations.
Specifications
Description
8x 10/100/1000 Ethernet PoE+ ports and 120W PoE budget, 2x 1G SFP and RJ-45 combo uplinks
Gigabit Ethernet ports
8
Uplink interfaces
2 SFP/ RJ-45 combo
PoE+power budget
120W
Fanless
Y
Dimensions (WxDxH in inches)
10.56 x 12.73 x 1.73
Console ports
RJ-45 Ethernet
1
USB mini-B
1
USB-A port for storage and Bluetooth console
1
Memory and processor
CPU
ARM v7 800 MHz
DRAM
512 MB
Flash memory
256 MB
Performance
Forwarding bandwidth
10 Gbps
Switching bandwidth
20 Gbps
Forwarding rate(64—byte L3 packets)
14.88 Mpps
Unicast MAC addresses
16000
IPv4 unicast direct routes
542
IPv4 unicast indirect routes
256
IPv6 unicast direct routes
414
IPv6 unicast indirect routes
128
IPv4 static routes
16
IPv6 static routes
16
IPv4 multicast routes and IGMP groups
1024
IPv6 multicast groups
1024
IPv4/MAC security ACEs
600
IPv6 security ACEs
600
Maximum active VLANs
256
VLAN IDs available
4094
Maximum STP instances
64
Maximum SPAN sessions
4
MTU-L3 packet
9198 bytes
Jumbo Ethernet frame
10,240 bytes
Dying Gasp
Yes
MTBF in hours (data)
2,171,669
MTBF in hours (PoE)
1,786,412, 1,706,649 (External PS)
MTBF in hours (Full PoE)
1,706,649
Environmental
Operating temperature Seal level
-5 to 50 deg C*
Up to 5,000ft (1500 m)
-5 to 45 deg C
Upto 10,000 (3000 m)
-5 to 40 deg C
Operating altitude
10,000 ft (3,000m)
Operating relative humidity
5% to 90% at 40C
Storage temperature
-13 to 158F (-25 to 70C)
Storage altitude
15,000 ft (4500m)
Storage relative humidit
5% to 95% at 65C
