Matrix Switch Splitter
Experience seamless high-definition signal management with the DMInteract Video HDMI HD Matrix 4×4 Switch Splitter (Model: DM-HD4V4HD), engineered for professional AV installations and demanding multimedia environments. Supporting 4 HDMI inputs and 4 HDMI outputs, this 1U rack-mountable matrix switcher delivers brilliant 4K video at 60Hz with audio fiber output and synchronized switching, making it ideal for control rooms, home theaters, conference systems, and broadcasting setups. Built with a 13.5Gbps interface bandwidth, HDCP 1.3 compatibility, and advanced EDID handling, it ensures zero signal loss, enhanced color depth, and seamless device integration. The front-panel LCD offers real-time status display, while multiple control options—including RS-232, IR, remote, and TCP/IP—guarantee flexibility and convenience. Designed for stability and longevity, this HDMI matrix also boasts robust ESD protection and supports secondary development for advanced integration.
Specifications
Product Name
DMInteract DM-HD4V4HD 4K 60Hz 4×4 With Audio Fiber Out HDMI Matrix Switch Splitter
Weight
1.00 Kg
Frequency
50/60 Hz (Power frequency); Supports video output frequency up to 120Hz (e.g., 1080p@24/30/50/60/120Hz)
Resolutions
Supports 480i, 576i, 480p, 576p, 720p, 1080i, 1080p@24/30/50/60/120Hz; Max: HDPC 1920×1200@60, HDTV 1920×1080@60Hz
Input Interface
4×HDMI (HDMI 1.3a standard)
Input Source
Blu-ray DVD players, set-top boxes, and other HDMI-enabled HD signal source devices
Color Depth
Deep Color support for 48/36/30/24-bit; Supports RGB444, YUV444, YUV422, X.v.Color extended gamut
Output Interface
4×HDMI with audio fiber output
Control Method
Key panel, RS-232, IR remote, TCP/IP (LAN); Supports up to 16 PC clients for real-time control
Manufacturer
DMInteract
Color
Black
Country of Origin
China
DMInteract DM-HD4V4HD HDMI Matrix Switch Splitter, 4K Video Support, Audio-Video Synchronization, Broadcast-Grade Chip, Real-Time LCD Display, Flexible Control Options, Gray | DM-HD4V4HD
$530.00
High-Definition Input & Output Support: Compatible with HDMI 1.3a, the switcher supports resolutions up to 1080p at 120Hz and deep color up to 48-bit, ensuring sharp, vibrant visuals across all connected devices.
Audio-Video Synchronization with Multi-Format Support: Integrates embedded audio formats including LPCM 7.1CH, Dolby TrueHD, Dolby Digital+, and DTS-HD Master Audio for immersive, synchronized AV experiences.
Broadcast-Grade 6.5GHz Switching Chip: Utilizes a high-performance American broadcast-standard chip for stable operation, precise switching, and superior signal integrity.
Front LCD Display Panel: The integrated LCD screen provides real-time status of input/output signals and system configurations, streamlining monitoring and adjustments.
Flexible Rack-Mountable Design: Available in both 1U and 2U chassis options to support scalable setups—from 4×4 to 16×16 configurations—perfect for custom AV installations.
Multiple Control Interfaces: Supports key control, RS-232, IR remote, and TCP/IP protocols, offering effortless integration into a wide range of control systems.
Multi-User LAN Control Support: Enables up to 16 PC clients on the same network to simultaneously manage the matrix, with real-time synchronization of signal switching states.
Smart EDID Read/Write Functionality: EDID adaptive technology enhances compatibility with varied display types, eliminating screen issues like black edges or resolution mismatches.
HDCP and Signal Encryption Compatibility: Fully supports HDCP decryption for seamless use with Blu-ray players, set-top boxes, and other encrypted HD sources.
Advanced ESD Electrostatic Protection: Designed to withstand electrostatic discharges up to ±8kV (air) and ±4kV (contact), safeguarding the unit from electrical damage and ensuring long-term reliability.
| Brand |
DMInteract |
|---|---|
| Model |
Matrix Switch Splitter |
| Date first available |
21 April; 2025 |
| Shipping Weight |
4.00 Kg |
| Shipping Dimensions |
25.00 cm x 43.80 cm x 4.50 cm |
