NETGEAR GS752TPv3 48-Port PoE+ Compliant Gigabit Managed Network Switch (380W), 4x Gigabit SFP Ports, 104 Gb/s Switching Capacity, 77.38 Mpps Forwarding Rate | GS752TP-300UKS

GS752TPv3
Enhance your small-to-medium business’s network to support power over Ethernet (PoE) devices such as IP security cameras, access points, and VoIP phones with the GS752TPv3 48-Port Gigabit PoE-Compliant Managed Network Switch from Netgear. This managed rackmount switch features 48 PoE-compatible Gigabit Ethernet RJ45 ports, each of which can each supply 30W of power with a 380W budget to compatible devices. Integrated Layer 2 and Layer 2+ / Layer 3 Lite features, such as static routing, dynamic VLAN assignment, and automatic voice and video prioritization, help enhance overall performance and PoE functionality.
Netgear Insight
Netgear Insight Cloud management enables features that allow businesses to configure and deploy settings from anywhere using the Netgear Insight app from mobile devices or the Insight Cloud portal from any web browser. A 1-year subscription is included.
Dynamic VLAN Assignment
IP phones and PCs can authenticate on the same port but under different VLAN assignment policies. Users are free to move around and enjoy the same level of network access regardless of their physical location in the network.
Static Routing
A simple way to provide segmentation of the network with internal routing through the switch, reserving the router for external traffic routing only, making the entire network more efficient.
Robust Security
Secure your network against external attacks with features such as 802.1x authentication, DHCP filtering, port-based security by locked MAC, and ACL filtering based on MAC and IP addresses.
Auto VoIP Prioritization
Automatic Voice over IP (VoIP) prioritization simplifies most complex multi-vendor IP telephone deployments either based on protocols (SIP, H323, and SCCP) or on OUI bytes (default database and user based OUIs) in the phone source MAC address.
Specifications
Protocols
Layer Services Supported
Layer 2, Layer 3, Layer 4
Supported Protocols
Auto-VoIP, DHCP Server, DoS, IGMP Snooping, IPv4, IPv6, Link Aggregation, Port Mirroring, RADIUS, TLS
Queuing
Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support
10,000 Bytes
MAC Address Table Size
16K
Multicast Groups
512
Security
Security Features
DHCP Snooping, DoS Attack Prevention, Kensington Lock Support, RADIUS Authentication, Storm Control
Performance
Latency
2.5 to 3.3 µs
Forwarding Rate
77.38 Mpps
Switching Bandwidth
104 Gb/s (Non-Blocking)
Priority Queues
8
Packet Buffer
1.5 MB
Computer
Flash Memory
64 MB
CPU
Single-Core: Up to 800 MHz
Memory
512 MB
Electrical
PoE Power Budget
380 W
Power Draw
29.00 W (Idle), 861.00 W (Max)
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Supply Type
Internal
Environmental
Operating Temperature
32 to 82°F / 0 to 50°C
Operating Humidity
95%
Storage Temperature
-4 to 158°F / -20 to 70°C
Storage Humidity
95% (Non-Condensing)
Noise Level
36.6 dB
General
Certifications
CE, EN, VCCI, RCM, CCC, FCC, BSMI, Kcc, CB, UL
Cooling System
Fan
Mean Time Between Failures (MTBF)
1.4 Million Hours
Indicator Lights
Yes
Rack Mountable
Yes 1 RU
Dimensions
17.3 x 12.2 x 1.7″ / 440 x 310 x 43.2 mm
Weight
11.08 lb / 5.03 kg
