NETGEAR GSM4230UP 24-Port Gigabit PoE++ Managed Network Switch with SFP, 60 Gb/s Switching, 1440W Power Budget | GSM4230UP-100EUS

AV Line M425
M4250-26G4F-PoE++
Designed with input from industry professionals, the AV Line M4250 GSM4230UP 24-Port Gigabit PoE++ Compliant Managed Network Switch from Netgear is engineered for 1G AV over IP. Enjoy 24 rear-facing 60W PoE++ compliant RJ45 ports with a 1440W power budget and four Gigabit SFP uplink slots that ensure a clean integration in AV racks and pre-configuration for out-of-the-box functionality.
Key Features
24 x Gigabit Ethernet PoE++ Ports
4 x Gigabit SFP Ports
60 Gb/s Switching Capacity
44.64 Mpps Forwarding Rate
1.8 GHz ARM Cortex-A57 Quad-Core CPU
2GB RAM
Rack-Mountable Design
1440W Power Budget
AVB Support
Specifications
Interfaces
Inputs/Outputs
— 24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE (Type 4)
— 4 x 10/100/1000 Mb/s Gigabit SFP+
— 2 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Console)
— 2 x USB-C (Console)
— 1 x USB-A
Protocols
Layer Services Supported
— Layer 2 Support
— Layer 3 Support
Supported Protocols
— DHCP Server
— IGMP Snooping
— IPv4
— IPv6
— Link Aggregation
— Port Mirroring
— SNMPv1
— SNMPv2c
— SNMPv3
Jumbo Frames Support
12,000 Bytes
MAC Address Table Size
16K
VLAN Groups
4093
Security
Security Features
— DHCP Snooping
— DoS Attack Prevention
— RADIUS Authentication
— Storm Control
Access Control List
1024
SNMP Support
1, 2, 3
Standards
Supported IEEE Standards
— 802.3ab
— 802.3ac
— 802.3ad
— 802.3af
— 802.3at
— 802.3u
— 802.1ab
— 802.1ak
— 802.1as
— 802.1d
— 802.1p
— 802.1q
— 802.1qat
— 802.1qav
— 802.1s
— 802.1v
— 802.1w
— 802.1x
Performance
Forwarding Rate
44.64 Mpps
Switching Bandwidth
60 Gb/s
Packet Buffer
16 Mb
Computer
CPU
Quad-Core: Up to 1.8 GHz Cortex A (57)
Memory
2 GB
Electrical
PoE Power Budget
1440 W
PoE per Port
90 W
Power Supply Type
Internal
Environmental
Operating Temperature
32 to 77°F / 0 to 45°C
Operating Humidity
90%
Storage Temperature
-4 to 158°F / -20 to 70°C
Storage Humidity
95%
Operating Altitude
10,000′ / 3048 m
Storage Altitude
10,000′ / 3048 m
Noise Level
34.0 dB (Active)
General
Cooling System
Fan/Passive Combo
Indicator Lights
Link/Activity/Speed, PoE
Rack Form Factor
1 RU
Dimensions
17.3 x 10.1 x 1.7″ / 440 x 257 x 43.2 mm
Weight
9.5 lb / 4.3 kg
