Netgear XS724EM 24-Port 10-Gigabit/Multi-Gigabit Smart Managed Plus Switch with 2x 10G SFP+480 Gb/s Bandwidth, Up to 64 VLANs & Extensive L2 & L3 Services Supported, Gray | XS724EM-100EUS

10-Gigabit/Multi-Gigabit Plus (XS724EM)
24-Port 10G/Multi-Gigabit Plus Switch with 2 Dedicated SFP+ Ports
As a leading provider of network equipment for SMBs, NETGEAR® understands the importance of reliable and high-performance networks. With the growth of virtualization, cloud-based services, and applications like VoIP, video streaming, and IP surveillance, SMB networks need to extend beyond simple reliability to higher speed and performance. The 10-Gigabit and Multi-Gigabit Plus Switches from NETGEAR present the right solution for this requirement; delivering unprecedented non-blocking10-Gigabit bandwidth at the most affordable cost. All of them are perfect for removing the SMB network bottlenecks caused by the proliferation of Gigabit-to-the-desktop and the upcoming 10-Gigabit/Multi-Gigabit high-end workstations.
Key Features
24 x Gigabit Copper Ports
2 x Shared SFP+ Ports
480 Gb/s Bandwidth
32K MAC Address Table Size
Supports up to 64 VLANs
Supports up to 128 Multicast Groups
802.3az Energy Efficient Ethernet
Extensive L2 & L3 Services Supported
Link Aggregation
Quality of Service (QoS) Functionality
Specifications
Ports
100M/1G/2.5G/5G/10G RJ-45 Copper Ports
24
SFP+ Ports
2 (shared)
Form Factor
Rackmount
Packet Memory Buffer
3 MB
Bandwidth
480 Gb/s
MAC Address Database Size
32 K
VLANs
64
Number of Link Aggregation Groups (LAGs – 802.3ad)
8 LAGs with max. 8 members in each LAG
Multicast Groups
128
Port Mirroring
Max Number of Source Ports Allowed (many to one port mirroring)
23
Fans
2 (active fans)
802.3az Support
Yes
Max Power Consumption
76.56 W
LEDs
Power, Speed, Fan, Link/Activity
Acoustic Noise Levels
35.91 dBA
Operating Temperature
32 to 122°F / 0 to 50°C
Dimensions
17.3 x 8.0 x 1.7″ / 440 x 204 x 43 mm
Weight
8.21 lb / 3.72 kg
