Pro Max 48 PoE
A 48-port, Layer 3 Etherlightingâ„¢ switch with 2.5 GbE and PoE++ output.
Specifications
Mechanical
Dimensions
442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7″)
Weight
Without mounting brackets: 6.2 kg (13.7 lb)
With mounting brackets: 6.3 kg (13.9 lb)
Enclosure Material
SGCC steel
Hardware
Management Interface
Ethernet In-Band
Networking Interface
(32) GbE RJ45 ports
(16) 1/2.5 GbE RJ45 ports
(4) 10G SFP+ ports
PoE Interface
(32) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(16) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 😎
Total Non-Blocking Throughput
112 Gbps
Switching Capacity
224 Gbps
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP-RPS DC input
Power Supply
AC/DC, internal, 820W
Supported Voltage Range
100—240V AC
Max Power Consumption
100W (Excluding PoE output)
Total Available PoE
720W
Max PoE Wattage per Port by PSE
PoE: 15.4W
PoE+: 30W
PoE++: 60W
Voltage Range PoE Mode
PoE: 44—57V
PoE+: 50—57V
LCM Display
(1) 1.3″ touchscreen
Button
Factory reset
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Switching Features
Layer 2 Features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 Features
DHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs
LEDs
System
Status
RPS
Status
Application Requirements
UniFi Network
Version 8.0.24 and later
Ubiquiti Pro Max 48 PoE Network Switch, 1.3″ Touchscreen, 32x GbE RJ45 ports, 224 Gbps Switching Capacity, 720W Total Available PoE, SGCC Steel Material, Black | USW-Pro-Max-48-PoE (720W)
$1,340.00
Etherlightingâ„¢ ports that illuminate to indicate port location, speed/link, and native VLAN/network*
(16) 2.5 GbE ports including (8) PoE+ and (8) PoE++
(32) GbE ports including (24) PoE+ and (8) PoE++
(4) 10G SFP+ ports
DC power backup ready
720W total PoE availability
Managed with UniFi Network 8.0.24 and later
| Brand |
UBIQUITI |
|---|---|
| Model |
Pro Max 48 PoE (720W) |
| Date first available |
28 May; 2024 |
| Shipping Weight |
7.25 Kg |
| Shipping Dimensions |
12.00 cm x 54.00 cm x 52.01 cm |
