UV-9R Plus
UV-9R Plus is one of Baofeng’s noteworthy handheld radio models & a waterproof device you’d like to bring for outdoor activities.
Specifications
General
Frequency Range
U/V: 400-520MHz/136-174MHz
Channel No.
128
Frequency Stability
±1.5ppm
Operating Voltage
3.7V
Antenna Impedance
50Ω
Operating Temperature
-20℃ to +60℃
Channel spacing
25.0kHz / 12.5kHz
Battery Capacity
H-1800mAH (Li-ion battery)
Dimension L x W x H
113 x 55 x 34 mm including antenna
Transmitter
Transmitting power
≤8W
Modulation mode
16KΦF3E / 8KΦF3E
Modulation limit
≤5kHz / ±2.5kHz
FM distortion
≤5%
Residual FM
-45dB / -35dB
Adjacent channel power
-65dB / -55dB
Receiver
Sensitivity
0.15μV / 0.18μV
Adjacent channel selectivity
65dB / 55dB
Intermodulation Rejection
55dB
Spurious Response
≥60dB
Signal to noise ratio
40dB / 35dB
Rated audio output power
≥600mW
Rated audio distortion
≤5%
Baofeng UV-9R Plus Two Way Radio, Earpiece, Dual Band, Auto-Back Light, Time-out Timer, Voice Prompt, AUTO Keypad Lock, Emergency Alarm, Flashlight, Low Battery Warning, 20 Pack, Black | UV9RP
$570.00
Output : 8W(H)/4W(M)/1W(L)
Frequency Range: 136.00-174.00 MHz / 400.00-520.00MHz
IP67 waterproof and dustproof (Not diving)
High &Low Power Switchover
Battery Saving
VOX Function
| Brand |
BAOFENG |
|---|---|
| Model |
UV-9R Plus (20 Pack) |
| Date first available |
31 December; 2024 |
| Shipping Weight |
0.65 Kg |
| Shipping Dimensions |
6.00 cm x 16.50 cm x 27.51 cm |
