Canon imageFORMULA DR-M140II Document Scanner, CMOS CIS 1 Line Sensor, 600 DPI Optical Resolution, Simplex, Duplex, Skip Black Page & Folio Scanning Side, USB Interface, Black | 6050C003

imageFORMULA DR-M140II
Achieve high-speed, high-quality scanning with a compact and reliable device. Embrace updated, intelligent features to streamline workflows and save time.
Specifications
Type
Desktop Type Sheet Fed Scanner
Scanning Sensor Unit
CMOS CIS 1 Line Sensor
Optical Resolution
600dpi
Light Source
RGB LED
Scanning Side
Simplex / Duplex / Skip blank page / Folio
Interface
High Speed USB 2.0
Dimensions (WxDxH)
Tray Closed: 313 (W) x 181 (D) x 93 (H)mm Tray Opened: 313 (W) x 288 (D) x 93 (H)mm
Weight
Approx. 2.6Kg
Power Requirements
AC100 – 240V (50/60Hz)
Power Consumption
Scanning: 24.5W or less; Sleep Mode: 1.6W; Power Off: 0.1W or less
Operating Environment
10 – 32.5°C (50 – 90.5°F), Humidity: 20 – 80% RH
Environmental Compliance
RoHS
Scanning Specifications
Black and White
40ppm / 80ipm
Colour
40ppm / 80ipm
Output Resolution
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi, 1200 x 1200dpi
Output Mode
Black & White, Error Diffusion, Advanced Text Enhancement, 8-Bit Greyscale, 24-Bit Colour, Auto Colour Detection, Active Threshold
Suggested Daily Duty Cycle
From 6,000 to 8,500 scans/day
Document Specifications
Width
50.8 mm – 216 mm
Length
54 mm – 356 mm
Thickness
U-Turn: 0.04 – 0.15mm (27 – 128g/m²); Straight-through: 0.04 – 0.3mm (27 – 255g/m²)
Long Document Mode
5,588 mm Max
Business Card Scanning
Straight-through: 50.8 – 91mm (Thickness 380g/m² 0.45mm or less)
Paper Separation
Retard Roller Method (Reversing Separator Roller)
Feeder Capacity
80 sheets
Special Features
Automatic Page Size Detection, Deskew, 3D Colour Correction, Colour Dropout (RGB), Text Enhancement, MultiStream, Preset Gamma Curve, Edge Enhancement, etc.
Bundled Software
ISIS / TWAIN Driver, CaptureOnTouch Pro (Windows)
