Specifications
Image Sensor
CIS x 2
Light Source
LED
Optical Resolution
600 dpi
Hardware Resolution
600 x 600 dpi
Scan Modes
Color: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit
ADF Capacity
1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs)
2. 30 sheets (Business Cards, landscape feeding)
3. Plastic Card, Max. thickness under 1.2 mm landscape feeding
4. Passport: Less 4.0 mm (0.15 in.) thickness (including carrier sheet)
Note: To prevent passport damage, please scan with carrier sheet when scanning a passport. Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed ( ADF )
60 ppm/ 120 ipm (Grayscale/B&W mode, 200 dpi, A4 Portrait)
60 ppm/ 120 ipm (Grayscale/B&W mode, 300 dpi, A4 Portrait)
60 ppm/ 120 ipm (Color mode, 200 dpi, A4 Portrait)
60 ppm/ 120 ipm (Color mode, 300 dpi, A4 Portrait)
Note: Actual scanning speeds are affected by data transmission, software processing times with USB 3.0 connection and finally by the specification of the pc.
Scanning Area (W x L)
Max: 216 x 5080 mm (8.5” x 200”)
Min: 13.2 x 13.2 mm (0.52” x 0.52”)
Acceptable Paper Sizes (W x L)
Max: 244 x 5080 mm (9.65” x 200”)
Min: 50.8 x 50.8 mm (2” x 2”)
Acceptable Paper Weight (Thickness)
27 to 413 g/㎡ (7.2 to 110 Lbs)
Multi-feed Detection
With ultrasonic technology
Daily Duty Scan ( Sheets )
8,000
Separate Roller Lifetime (Scans)
300,000
Pick Roller Lifetime (Scans)
300,000
Friction Roller Lifetime (Scans)
100,000
Action Button
5 Buttons: Power, Up, Down, Cancel, Scan
9 function keys are all customizable.
Power Supply
24 Vdc/ 1.25 A
Interface
USB 3.2 Gen 1×1, USB 3.2 Gen 1×1 (Host) x1
Net Weight
4.1 Kgs (9.04 Lbs)
Dimensions (W x D x H)
319.9 x 298.2 x 236.6 mm (12.59″ x 11.74″ x 9.32″)
Protocol
TWAIN Compliant
Operating System
Windows 7 / 8 / 10 / 11
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
Hardware Requirements
2.5 GHz CPU processor or higher[1]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
USB Port: USB 3.0 Port (USB 2.0/1.1 supported)
Display dimensions of 1024×768 or greater
Bundled Software
Plustek DocAction
Plustek DocTWAIN
Built-in OCR
Plustek OCR
(Powered by ABBYY® FineReader®)
