Idemia Visionpass SP MD, 5″ WVGA Color Capacitive Touchscreen, Multi-Core 1.8 GHz + NPU, 4GB RAM, 16GB Flash, Ethernet & RS485, 60 GHz Radar, Buzzer, Black | 293803151

Visionpass SP MD
Specifications
CPU
Multi-Core 1.8 GHz + NPU
Display
5-inch WVGA color capacitive touchscreen
Facial Acquisition
2 x 2 MP visible/IR, 3D stereovision
Lighting
White and infrared LEDs
Proximity Sensor
60 GHz radar
Sound
Buzzer
Facial Performance
Intention area 0.3 to 1.0 m (adjustable), Field of view (HxV): 55°x90°, User height from 1.2 to 2.0 m, Matching speed
Contactless Reader Options
MIFARE/DESFire
Internal Storage Capacity
16Gb Flash and 4Gb RAM, Up to 10,000 users in the database, 250,000 IDs in authorized user list, 1 million transaction logs
Security
Secure booting and authenticity check, Cryptographic technologies for sensitive data security, Data protection with AES-256 database encryption, Network communication encryption with TLS 1.2, Network authentication with 802.1.X, OSDP secure channel, Tamper switches
Network/Communication
Ethernet, RS485
Inputs/Outputs
Wiegand in and out, OSDP, door relay, three GPI (including door monitoring), three GPO
Power Supply
12 to 24 V DC (2.5 A min @12V), Power over Ethernet with PoE+ switches
Operating Conditions
Temperature: -10°C to 45°C (14°F to 113°F), Humidity: 10% to 80% (non-condensing)
Intrusion Protection
IP65
Dimensions and Weight
HxWxD: 21×10.2×3.5 cm (8.2”x4”x1.4”), Weight: 0.8 kg
EMC/Safety Standards
CE, CB, FCC
Compliance
RoHS, REACH, California Proposition 65, WEEE
Manufacturing
Made in France
