The Camera AI 360 (AI 360) is a pan-tilt-zoom (PTZ) camera that provides panoramic, overhead surveillance of heavily populated indoor and outdoor areas. The AI 360 streams sharp 1920×1920 video at a smooth 30 frames per second (FPS), and its built-in IR LEDs ensure that every frame is crystal clear—day or night. Equipped with a 5 MP CMOS sensor and an ultra-wide, 360° fisheye lens, the AI 360 can quickly detect finite details within its expansive coverage area and capture them with pristine clarity. It’s also protected with rugged, weather and tamper-resistant housing, making it an ideal choice for shopping centers, parking lots, airports, train stations, and other transportation hubs. The AI 360 is a sophisticated, feature-rich camera, but it’s also designed to be incredibly easy to set up and incorporate into existing Protect deployments. It can be adopted in minutes and managed with either the UniFi Protect web application or mobile app.
Key Features
Captures 1920×1920, 30 FPS video
5 MP CMOS sensor
Ultra-wide, 360° fisheye lens
IPX4-rated, weatherproof housing
IK08-rated tamper resistance
Built-in IR LEDs for clear nighttime surveillance
Powered by PoE
Specifications
Mechanical
Dimensions
Ø147 x 49 mm (Ø5.8 x 1.9″)
Weight
Without mount: 655 g (1.4 lb)
With outdoor accessory: 685 g (1.5 lb)
Enclosure material
Aluminum alloy, polycarbonate, hard-coated dome
Mount material
Polycarbonate, stainless steel
Weatherproofing
IPX4
Resistance
IK08
Optics
Sensor
5MP CMOS
Lens
Fisheye lens
View angle
360°
Night mode
Built-in IR LED illumination and IR cut filter
Video
Video compression
H.264
Resolution
4MP 1920 x 1920 (1:1)
Max. frame rate
30 FPS
Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, masking, text overlay
System
Processor
Quad-core Arm® Cortex®-A53 based chip
Networking interface
GbE RJ45 port
Power method
PoE
Power supply
48V DC, 0.18A PoE
Max. power consumption
8.64W
Supported voltage range
37—57V DC
LED
R/G/B/W
Button
Factory reset
Mounting
Surface mount
Operating temperature
-20 to 40° C (-4 to 104° F)
Operating humidity
10 to 90% noncondensing
Certifications
FCC, IC, CE
Audio
Microphone
Yes (Can be disabled)
Speaker
Yes
Software
Web application
UniFi Protect: Version 1.10.0 and later
Mobile app
UniFi Protect iOS™ and Android™
