AMD Ryzen 7 8000 G-Series Desktop Processors with Radeon Graphics
Ryzen 7 8700G
With eight cores, 16 threads, and a dedicated AI engine, the AMD Ryzen 7 8700G 4.2 GHz Eight-Core AM5 Processor brings your gaming and content-creation experiences to new levels. Designed for socket AM5 motherboards using the powerful Zen 4 architecture with the 4nm process, this Ryzen processor delivers significantly improved performance compared to its predecessor while maintaining high energy efficiency.
Key Features
8 Cores & 16 Threads
4.2 GHz Base Clock
5.1 GHz Max Boost Clock
Socket AM5
8MB L2 & 16MB L3 Cache
Integrated AMD Radeon 780M Graphics
DDR5-5200 Memory
Unlocked Processor | AMD Ryzen AI
Zen 4 Architecture
Specifications
Details
Platform
Desktop
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 7 8000 G-Series Desktop Processors with Radeon™ Graphics
AMD PRO Technologies
No
Consumer Use
Yes
Regional Availability
Global
Former Codename
“Phoenix”
Architecture
“Zen 4”
# of CPU Cores
8
Multithreading (SMT)
Yes
# of Threads
16
Max. Boost Clock
Up to 5.1GHz
Base Clock
4.2GHz
L2 Cache
8MB
L3 Cache
16MB
Default TDP
65W
AMD Configurable TDP (cTDP)
45-65W
Processor Technology for CPU Cores
TSMC 4nm FinFET
CPU Compute Die (CCD) Size
178mm²
Package Die Count
1
Unlocked for Overclocking
Yes
AMD EXPO™ Memory Overclocking Technology
Yes
Precision Boost Overdrive
Yes
Curve Optimizer Voltage Offsets
Yes
AMD Ryzen™ Master Support
Yes
CPU Socket
AM5
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax)
95°C
Launch Date
1/31/2024
OS Support
Windows 11 – 64-Bit Edition, Windows 10 – 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit (OS support may vary by manufacturer)
Connectivity
–
Native USB 4 (40Gbps) Ports
2
Native USB 3.2 Gen 2 (10Gbps) Ports
2
Native USB 2.0 (480Mbps) Ports
1
PCIe Version
PCIe 4.0
Native PCIe Lanes (Total/Usable)
20 / 16
NVMe Support
Boot, RAID0, RAID1
System Memory Type
DDR5
Memory Channels
2
Max. Memory
256GB
System Memory Subtype
UDIMM
Max Memory Speed
–
Graphics Capabilities
–
Integrated Graphics
Yes
Graphics Model
AMD Radeon™ 780M
Graphics Core Count
12
Graphics Frequency
2900 MHz
DirectX Version
12
DisplayPort Version
2.1
DisplayPort Extensions
HDR Metadata, Adaptive-Sync, UHBR10
DisplayPort Max Refresh Rates (SDR)
7680×4320 @ 60Hz, 3840×2160 @ 240Hz, 3440×1440 @ 360Hz, 2560×1440 @ 480Hz, 1920×1080 @ 600Hz
DisplayPort Max Refresh Rates (HDR)
7680×4320 @ 60Hz, 3840×2160 @ 240Hz, 3440×1440 @ 360Hz, 2560×1440 @ 480Hz, 1920×1080 @ 600Hz
HDMI Version
2.1
HDCP Version Supported
2.3
USB Type-C DisplayPort Alternate Mode
Yes
Multi-Monitor Support
Yes
Max Displays
4
AMD FreeSync™
Yes
Wireless Display
Miracast
